Engine T-Motor MN505-S KV320

Technical details and compatibility

The MN505-S KV320 is built for serious work. Its peak current reaches 55A, demonstrating its power. Be sure to use compatible ESCs with enough reserve. We recommend quality speed controllers from T-Motor. This will ensure that the motor fully unleashes its potential.

The manufacturer T-Motor is a synonym for reliability in the UAV world. Their products meet strict quality standards. By choosing this engine, you are investing in stability. It is suitable for FPV racing, filming platforms and industrial drones. Versatility is another advantage.

Use the recommended 20″ or 22″ propellers for best results. Proper propeller selection is critical. It affects the thrust, efficiency, and life of the motor. Always balance the propellers before installation. This will reduce vibration and extend the life of the bearings.

Technical specifications

• Weight: 225 g
• Wire length: 150mm
• KV:320
• Maximum thrust: 6.7 kg
• Peak power: 1300 W
• Peak current: 55 A
• Manufacturer: T-Motor
• Propeller:20″, 22″
• Recommended battery:6S
• Resistance: 38 mOhm
• Section (AWG/Gauge):16
• No-load current: 1.8 A
• Degree of protection (dust and moisture resistance): IP45.
